Advanced functional materials

Precision chemistry for next-generation solar manufacturing.

High-performance masking inks and insulating adhesives engineered for stable, efficient photovoltaic production.

NORTH AMERICAN R&D MANUFACTURING IN CHINA GLOBAL SERVICE

Materials that perform on the line.

A focused portfolio for back-contact and electroplated solar cell processes—built around adhesion, chemical resistance and production efficiency.

Amber masking ink applied across a photovoltaic cell surface
01 / MASKING

Acid-resistant plating ink

A precision masking material developed for next-generation BC and electroplated cells, combining strong acid resistance with rapid alkaline stripping.

Viscosity70,000–90,000 cps
Acid resistance30% H₂SO₄ · ≤40°C · 1 h
Adhesion / hardness5B / H–2H
Alkaline strip≤30 s at 25°C
Layered insulating adhesive protecting photovoltaic cell electrodes
02 / INSULATION

Thermosetting insulating adhesive

A two-component, low-temperature cure system with excellent adhesion to metal, glass and plastics, designed for demanding BC electrode protection.

Cure100–110°C / 20 min
Adhesion / hardness5B / ≥6H
High-temperature test350°C · 30 min · ΔE < 0.5
Volume resistivity>10¹⁴ Ω·m
UV LED curing an insulating adhesive pattern on a production line
03 / HIGH-SPEED CURE

UV insulating adhesive

Fast UV LED curing for high-throughput automated lines, with broad substrate compatibility, chemical resistance and proven use in BC cell production.

Viscosity10,000–30,000 cps
Hardness5H–6H
PCT test120°C · 0.1 MPa · 2 h · 5B
Volume resistivity>10¹⁴ Ω·m

Built for manufacturing confidence.

From formulation through scale-up, 3H combines disciplined quality systems with responsive technical collaboration.

Reliable

International-grade quality control supports consistent production yield.

Responsive

Local technical support keeps qualification and troubleshooting moving.

Supply-ready

China-based manufacturing strengthens delivery continuity and lead-time control.

Adaptive

Rapid formulation development for emerging high-efficiency processes.

One integrated material partner

Global expertise. Local production certainty.

3H Chimie is a technology-driven materials company focused on high-performance specialty inks, polymer coatings and photovoltaic process materials. North American formulation expertise connects directly to scaled manufacturing and application support in China.

North American R&D Manufacturing in China Global customer support

Let’s solve the next process challenge.

Discuss material selection, qualification testing or a custom formulation with our technical team.
